Our 3600 ONFI PHY is a silicon proven complete IP solution, including I/O, PMA, PCS and test engine with optional one-tap DFE. The IPT 3600 ONFI PHY facilitates high-speed data transfer between NAND flash memory and host controllers. This interface is crucial for enhancing the performance and reliability of storage solutions in various applications, from consumer electronics to industrial systems.

Key Features

l  Silicon proven

l  Supports Both NV-DDR3 and NV-LPDDR4 with optional 1-tap DFE

o    NV-DDR3 up to 3,600 MT/s

o    NV-LPDDR4 up to 3,600MT/s

l  Support Decision Feedback Equalization (DFE): For extra high loading, DFE can reduce errors and improve data integrity

l  Compliant with JEDEC 5.1 and JESD 230F specifications

l  Supports real-time PVT data-eye monitoring

l  Supports all required trainings and calibrations

l  Supports Power-Down Modes

o    Active

o    Low-power Run

o    Sleep

o    Low Power Sleep

o    Standby

o    Hibernate

l  Compliant with AMBA APB3.0 for register accessing
